EV CHARGER TYPE 1
PRODUCT DESCRIPTION
EV CHARGER TYPE 1
7KW,Home version Plug and play, RFID card, WIFI & Bluetooth APP are optional; Commercial version OCPP1.6, Ethernet, WIFI & Bluetooth APP, 4G is optional.
FEATURES
●Strong compatibility with electric car models
●Multiple intelligent detection and protection functions
●Voltage & Current detection and accurate power calculation
●4.3-inch LCD displays standby, charging and fault status
●Various authorization modes with plug-and-charge, RFID card
charging, App charging, etc.
●Various charging methods of automatic full charging, reservation
charging, etc.
●CE mark certified, CQC compliant
APPLICABLE SCENES
- Suitable for home use in residential areas, private houses, and condos.
- Suitable for commercial use in office buildings, urban complexes.
- Suitable for parking lots, public charging station, etc.
- Suitable for New Energy Vehicle 4S Stores, workshop commissioning, driving school, etc.
SCAN THE QR CODE AND DOWLOAD THE APP TO COMPLETE INSTALLATION
PRODUCT SPECIFICATIONS
| Output Power | 7KW/9.6KW/11KW |
| Operating Current | 32A/40A/48A |
| Operating Voltage | L1/L2/PE;240 Vac (± 15%) |
| Cable Length | 5m/7.5m |
| Connector Type | Type 1 |
| Indicator | 3 -color Indicator |
| User Interface | 4.3 inches LCD Display Screen |
| Installation Method | Wall box/Floor Mounted |
| Communication Method | Wifi and Bluetooth |
| Warranty | 2 years |
